Steel detailing & estimating · Texas
Shop drawings that fit the first time.
3D models and shop & erection drawings for steel fabricators, and steel takeoffs for your bids: structural steel, stairs and rails, miscellaneous metals and plant platforms.
Quotes within one business day · Se habla español · Walk through a 3D model
Two ways we work with your shop
From the bid to the shop floor
New · Estimating
Steel takeoffs for your bids
Send the bid drawings; get every beam, column, plate, bolt and rail counted in Excel, ready for your prices, with our detailing quote for the job.
- From $250 per takeoff
- 14-day free trial · first takeoff free · cancel anytime
- projects since 2021
- 111
- years in steel detailing
- 30+
- industrial & plant jobs
- 32
- bilingual office
- EN / ES
Counted from our own job records.
3D models
Walk through the steel before it's cut
These are real job models. Open one and follow the guided tour, or turn it yourself.
3DPublic library
A sweeping curved roof, with every beam and connection following its shape. About 13,000 parts.
Open the model
3DCommunity center
Stairs, guardrails and an elevated running track. Guided tour with 14 stops.
Open the model
3DCity hall
Three floors of framing, roof structure, stairs, rails and misc. metals: about 12,000 parts.
Open the modelSample drawings
What our sheets look like
Excerpts from issued-for-construction sets we detailed: erection plans, stair sheets, ISO views, shop drawings and a single-part sheet. Click any sheet to see it full size.
ISO views
Shop drawings
